Database Backup and Recovery Best Practices

1 .Database Backup and Recovery Best Practices (with a focus on MySQL) • Manjot Singh, Data & Infrastrustructure Architect 

2 .About Manjot Singh • MySQL Fanatic • Long time user (~16 years) • Database and Systems Administrator for a number of years • Oracle, SQL Server, MySQL • Now an Architect at Percona, helping many companies scale databases and systems and implement best practices 

3 .About Percona • Percona Delivers enterprise-class software, support and consulting solutions for MySQL and MongoDB • We have a global 24x7x365 consulting team • Percona consults with some of the largest companies on the internet as well as new startups • Percona Consultants have decades of experience solving complete database and performance issues 

4 . Do I Need to Take Database Backups? 

5 .YES!!! 

6 .Why Backup and Recovery? • Backup and Recovery processes are a critical part of any application infrastructure. • A well tested backup and recovery system can be the difference between a minor outage and the end of your business. 

7 .Recovery Requirements Determine Backups Three important questions define backup and recovery systems for organizations: • Recovery Time Objective • Recovery Point Objective • Risk Mitigation 

8 .Recovery Time Objective (RTO) • The amount of time that may pass during a disruption before it exceeds the maximum allowable time specified in the Business Continuity Plan • How long does it take you to get back up? 

9 .Recovery Point Objective (RPO) • Duration of time and service level within which a business process must be restored after a disaster in order to avoid unacceptable consequences associated with a break in continuity • “How much data can I lose?” • When was the last backup before failure? 

10 .Risk Mitigation What failure scenarios must the data be protected against? 

11 .Risk Mitigation Backups: • Can help mitigate failure scenarios • (Multiple) Host Failure • (Multiple) Data Center Failure • Data Corruption or Loss • Satisfy Legal Regulations • Legislation • Regulation • Fulfill Industry Standards • PCI • HIPAA • etc 

12 .Designing a Backup and Recovery System • Based on the RTO, RPO, and address whatever risks are applicable • Not all data should have the same requirements • For example HR database could have a longer RTO than your customer facing product database. Cost of 1 hour outage for HR is small compared to not accepting orders for 1 hour. 

13 .Types of Backups 

14 .Physical or Binary Backup • A physical backup typically refers to a copy of the entire on disk database • Used to mitigate a single or multiple host failure • Can build replicas • Quick Full Recovery Time • Slow to recover single row or table (user error) 

15 .Physical or Binary Backup • MySQL • Percona XtraBackup (takes a copy of the data directory and applies logs) • MySQL Enterprise Backup • LVM or VM Snapshot 

16 .XtraBackup - Backup Standard use: [mysql-master]# xtrabackup --backup --target-dir=/backup --user=root --password=X [mysql-master]# xtrabackup --prepare --target-dir=/backup Prepare was previously apply-log 

17 .XtraBackup - Restore Standard use: [mysql-restore]# scp –r mysql-master:/backup [mysql-restore]# xtrabackup --copy-back --target-dir=/backup/ [mysql-restore]# chown –R mysql.mysql /var/lib/mysql 

18 .Logical Backup • Generates SQL files containing data that can regenerate a database • Easily restore single row, table, or database • Works across versions • SQL (such as mysqldump) can be parsed with standard UNIX tools • Restore process automatically replicated • Long Full Restore Time 

19 .Logical Backup • MySQL • mysqldump • mysqlpump (5.7+) • mydumper • Delayed slave can also fit similar use cases 

20 .mysqldump - Backup Standard use: [mysql-master]# mysqldump –triggers –routines –events –single-transaction –all-databases -r dump.sql 

21 .mysqldump - Restore Standard use: [mysql-restore]# scp mysql-master:dump.sql [mysql-restore]# mysql < dump.sql [mysql-restore]# # OR: [mysql-restore]# mysql mysql> source dump.sql 

22 .Which is best? BOTH! Binary Backups Address Host Logical Backups address data Failure corruption and user error 

23 .Binary Logs • Addresses RPO • Logs should be rotated and backed up • Combine with a Binary Backup to allow Point in Time recovery • If you backup logs every hour, your RPO is 1 hour in case of a failure • Can be reduced, but not to the point where the i/o and network traffic interfere with database operations • Can stream logs for real-time RPO • Adding complexity increases recovery time due to more complicated recovery procedures 

24 .Binary log streaming mysqlbinlog --raw --read-from-remote-server --stop-never --host mysql- master --port 3306 -u repl –p somepass 

25 .Binary log streaming 

26 .Binary log streaming 

27 .Binary log streaming nohup livebinlog.sh server2.conf 2>&1 > livebinlog-server2.log & More information: https://www.percona.com/blog/2012/01/18/backing-up-binary-log-files-with-mysqlbinlog/ 

28 .Other Considerations 

29 .Retention • Protect Against Data Center Failure • Keep multiple backups • Counting on a single backup is a risk • Corruption • Malicious data • User error • Store important data offsite § Cloud storage – Google Nearline, Amazon Glacier § Vaulting – Ship drives/tapes § DR site
